Winter 2023 - Vol. 18, No. 4 CLINICAL PRESENTATION
A 56-year-old male with a past medical history of hypertension, hyperlipidemia, and benign prostatic hyperplasia presents to the emergency department (ED) for severe mid-sternal chest pain with exertion, without associated dyspnea. He describes a pressure/ burning-like sensation that radiates to the left arm and is associated with a numbness/tingling sensation. He notes similar episodes for the previous two weeks, but pain has subsequently become worse. The patient has taken three to four ibuprofen pills daily but denies acid reflux symptoms. He also has been under a great deal of stress as a caregiver for a family member.

In the ED, the chest discomfort decreases to 3/10 after receiving three sublingual nitroglycerin tablets and intravenous morphine. The pain is reproducible and worsens with movement of his arm; he has musculoskeletal arthralgias but no other complaints on a review of systems.

His past medical history includes benign prostatic hypertrophy, hypercholesterolemia, and hypertension. He had a normal cardiac catheterization in 2008. The patient’s family history includes diabetes and hypertension but not heart disease, and he has never smoked and says that he only drinks small amounts on social occasions.

His medications include albuterol inhaler as needed, atorvastatin 20 mg daily, ibuprofen 600 mg as needed, lisinopril 10 mg daily, tamsulosin 0.4 mg twice daily, and triamterene-hydrochlorothiazide (Dyazide®) 37.5 mg/25 mg daily.

On physical examination, he is afebrile with normal vital signs. He appears uncomfortable, moaning and groaning, with no other focal findings. Labs reveal an elevated fifth-generation troponin test of 121.80 ng/L; repeated two hours later, that number rises to 154 ng/L. The comprehensive metabolic panel and complete blood count are unremarkable, and an electrocardiogram is normal.

Computed tomography (CT) scan of the head without contrast reveals no intracranial hemorrhage, mass effect, or midline shift. A chest X-ray series demonstrates a normal cardiomediastinal silhouette, clear lungs, and bones that appear grossly unremarkable; however, there is mild hilar lymphadenopathy. CT angiogram of the chest reveals no evidence of pulmonary embolism, but again there is hilar and mediastinal lymphadenopathy.

The working diagnosis is non-ST-elevation myocardial infarction, thus a cardiology consult is obtained to consider cardiac catheterization. In the meantime, an echocardiogram is essentially normal with a left ventricular ejection fraction of 55% to 60% with normal diastolic function, and there is no evidence of left ventricular regional wall motion abnormality and no significant valvular pathology.

Cardiac catheterization reveals mild coronary artery disease with a 20% ostial left circumflex artery stenosis. There is no evidence of a recanalized lesion, distal cutoff, or spontaneous coronary artery dissection. Since the echocardiogram did not reveal any regional wall motion abnormalities, the acute myocardial injury is felt to be of unclear mechanism.

A cardiac MRI is performed and reveals normal biventricular function with no segmental wall motion abnormalities, with normal left and right ventricular ejection fractions. There is focal myocardial delayed enhancement at the basal inferolateral wall extending from the mid-myocardium to epicardial region (see Fig. 1). This is suspicious for cardiac sarcoidosis (CS), particularly given the abnormal findings on the chest radiography.


Fig. 1. Cardiac MRI images demonstrating a subepicardial inferolateral delayed enhancement pattern in short-axis imaging (left) and three-chamber long-axis imaging (right).

Prior myocarditis could also be included in the differential diagnosis. There is no evidence of edema on short tau inversion recovery (STIR) imaging, a finding that may have suggested acute myocarditis. No significant valvular dysfunction is noted; trace pericardial effusion is reported, yet no abnormal pericardial thickening or enhancement is found.

DISCUSSION
The initial diagnosis was non-ST-elevation myocardial infarction. This was modified after cardiac catheterization to myocardial infarction with no obstructive coronary atherosclerosis (MINOCA) versus non-ST-elevation myocardial infarction type 2 (NSTEMI type 2).¹ MINOCA is a clinical syndrome defined by evidence of a myocardial infarction with no significant coronary artery disease (<50% stenosis severity).

The Fourth Universal Definition of Myocardial Infarction, published by the European Society of Cardiology in 2018, added MINOCA as a subset of myocardial infarction, requiring three criteria for diagnosis^2,3:

1. The diagnosis of myocardial infarction must be established.
2. Coronary arteriography should reveal non-obstructive (<50% stenosis) coronary arteries.
3. No other diagnosis, such as pulmonary embolism or renal failure, can explain the clinical presentation.

Patients with MINOCA are more likely to be female and younger, in comparison with NSTEMI type 1.⁴ MINOCA represents 6% (range 1% to 14%) of all myocardial infarctions and can be subcategorized into coronary, cardiac, and non-cardiac causes (see Table 1). In a meta-analysis, in-hospital mortality of MINOCA is 0.9%, and one-year mortality is 4.7%.^5,6


Source: Niccoli et al.7

DIAGNOSTIC TECHNIQUE
Cardiac MRI is helpful in elucidating the etiology of MINOCA. It is the preferred next test after both echocardiography and cardiac catheterization do not reveal a clear etiology of the myocardial infarction.⁸ Early use of cardiac MRI enables identification of potentially reversible causes and assists in treatment/prognosis. Failure to identify causes can lead to undertreatment.

Late gadolinium enhancement (LGE) on cardiac MRI is believed to reflect myocardial fibrosis. Additional imaging techniques, such as T1 mapping, extracellular volume (ECV), T2 mapping, and STIR weighted imaging, can reveal evidence of acute myocarditis. Varying patterns of LGE correlate with and suggest specific cardiac pathologies without necessitating myocardial biopsy for tissue characterization. These include infarction, myocarditis, and cardiomyopathies.

Quantification of the extent of myocardial LGE helps stratify the prognosis. Approximately 25% of patients with MINOCA are found to have a normal myocardium after cardiac MRI, and a clear etiology of the presentation is not elucidated. Cardiac MRI reclassifies 68% of patients with MINOCA and confirms myocardial infarction in 22%, providing valuable diagnostic and prognostic information (see Fig. 2).⁹ Transesophageal echocardiography can be considered in cases of suspected coronary artery embolism.



TREATMENT OF MINOCA
Dual antiplatelet therapy with aspirin and P2Y12 inhibition have not been found to improve outcomes in MINOCA. Statin and angiotensin-converting enzyme inhibitors/angiotensin receptor blockers use resulted in a 23% and 18% reduction in major adverse cardiovascular outcomes, respectively, in the SWEDEHEART registry consisting of more than 9,000 MINOCA patients.¹⁰ Beta-blocker therapy may have provided some benefit to patients in this registry, but there have been no major randomized clinical trials of this treatment for patients with MINOCA.

In our patient, a CT angiogram of the chest revealed mediastinal and hilar lymphadenopathy with no evidence of pulmonary embolism, and the cardiac MRI demonstrated subepicardial delayed gadolinium enhancement of the inferolateral wall, consistent with cardiac sarcoidosis. Therefore, CS was the working diagnosis.

The patient did not demonstrate ventricular arrhythmias and did not undergo an electrophysiology study. Instead, he was discharged from the hospital with a plan for outpatient telemetry monitoring and positron emission tomography (PET) scan. The latter was unremarkable, suggesting burnt-out CS without active inflammation. Immunosuppressive therapy for CS was not initiated.

CS PREVALENCE AND TREATMENT OPTIONS
Sarcoidosis is a heterogeneous multisystem disease of unknown etiology, characterized by the formation of noncaseating granulomas.¹¹ The etiology of CS is unknown. Approximately 5% of patients with sarcoidosis have cardiac involvement, making CS a rare condition. Up to 25% of CS cases are isolated without involvement of extracardiac tissues.^12,13

Countries in more northern latitudes may have higher prevalence of cardiac sarcoidosis, like sarcoidosis in general, yet registries are incomplete.¹⁴ It can present asymptomatically, although patients may have ventricular arrhythmia or high-grade block, may experience palpitations or syncope, and may even present with congestive heart failure (CHF) or with sudden cardiac death. Atrial arrhythmias are uncommonly associated with CS.

Approximately 14% of CS patients initially present with sudden death. Sudden death due to ventricular tachyarrhythmias or conduction block accounts for 25% to 65% of CS-associated mortality. CHF accounts for 20% of initial presentations. Elevated levels of cardiac troponins, serum angiotensin converting enzyme (ACE), and urinary calcium have been reported in CS.

Computed tomography, cardiac MRI, and cardiac PET scans are utilized in the diagnosis,^15-18 which can be very difficult to establish.¹⁹ Imaging techniques, diagnostic criteria for extra-cardiac disease, and endomyocardial biopsy are utilized to confirm the diagnosis. Cardiac MRI and PET scanning (see Table 2) are often used as diagnostic gold standards for CS.^20-23 Varying patterns of myocardial delayed enhancement on cardiac MRI and fluorodeoxyglucose (FDG) uptake on PET scanning correlate with an increased likelihood of CS.²⁴



Endomyocardial biopsy is generally reserved for cases of high clinical suspicion with non-diagnostic imaging.^25,26 Given the sparse location of myocardial granulomas, random septal biopsy may result in a high rate of falsely negative specimens.

Histological confirmation of noncaseating granuloma on extracardiac biopsy can help confirm the diagnosis in the right clinical setting. Therefore, cardiac MRI may play a greater role in risk stratification of patients with systemic or suspected cardiac sarcoidosis. Further, biventricular LGE is associated with markedly increased odds of ventricular arrhythmias (OR = 43.6; 95% CI: 16.2-117.2), and the absence of delayed enhancement is associated with a very low risk of adverse cardiac events and likely excludes the presence of cardiac sarcoidosis.

Treatment options for CS can include immunosuppressants to improve ejection fraction and decrease ventricular arrhythmias associated with active inflammation^24,27,28 (see Fig. 3).


Fig. 3. A suggested algorithm for the diagnosis and immunosuppressive treatment of cardiac sarcoidosis. Adapted from Vita et al.²³

Prednisone in doses of 60 mg to 80 mg/day have been suggested and may be tapered if effective to a maintenance dose of 10 mg to 15 mg/ day. In those patients for whom this is not effective, anti-malarial drugs, methotrexate, or azathioprine should be considered.²⁹

High-grade atrioventricular block necessitates pacemaker implantation. However, when ventricular arrhythmias cannot be controlled, antiarrhythmic therapy, catheter ablation, and cardioverter defibrillator implantation may be necessary. Recent data suggest that the presence and quantity of abnormal delayed enhancement during cardiac MRI correlates significantly with an increased risk of ventricular arrhythmias and mortality (see Fig. 4).²⁸


Fig. 4. Prognostic significance of late gadolinium enhancement (LGE) with known or suspected cardiac sarcoidosis. Adapted from Stevenson et al.²⁸

Refractory ventricular arrhythmias and heart failure may necessitate advanced heart failure therapies, such as biventricular assist device or cardiac transplantation.

REFERENCES
1. Agewall S, Beltrame JF, Reynolds HR, et al. ESC working group position paper on myocardial infarction with non-obstructive coronary arteries. Eur Heart J. 2017;38(3):143-153.
2. Rossini R, Capodanno D, Lettieri C, et al. Long-term outcomes of patients with acute coronary syndrome and nonobstructive coronary artery disease. Am J Cardiol. 2013;112(2):150-155.
3. Abdu FA, Mohamed AQ, Liu L, Xu Y, Che W. Myocardial infarction with nonobstructive coronary arteries (MINOCA): a review of the current position. Cardiology. 2020;145(9):543-552.
4. Reynolds HR, Srichai MB, Iqbal SN, et al. Mechanisms of myocardial infarction in women without angiographically obstructive coronary artery disease. Circulation. 2011;124(13):1414-1425.
5. Pelliccia F, Pasceri V, Niccoli G, et al. Predictors of mortality in myocardial infarction and nonobstructed coronary arteries: a systematic review and meta-regression. Am J Med. 2020;133(1):73-83.e4.
6. Pasupathy S, Air T, Dreyer RP, Tavella R, Beltrame JF. Systematic review of patients presenting with suspected myocardial infarction and non-obstructive coronary arteries [published correction appears in Circulation. 2015;131(19):e475]. Circulation. 2015;131(10):861-870.
7. Niccoli G, Scalone G, Crea F. Acute myocardial infarction with no obstructive coronary atherosclerosis: mechanisms and management. Eur Heart J. 2015;36(8):475-481.
8. Reynolds HR, Maehara A, Kwong RY, et al. Coronary optical coherence tomography and cardiac magnetic resonance imaging to determine underlying causes of myocardial infarction with nonobstructive coronary arteries in women [published correction appears in Circulation. 2023;147(8):e624]. Circulation. 2021;143(7):624-640.
9. Mileva N, Paolisso P, Gallinoro E, et al. Diagnostic and prognostic role of cardiac magnetic resonance in MINOCA: systematic review and meta-analysis. J Am Coll Cardiol Img. 2023;16(3):376-389.
10. Lindahl B, Baron T, Erlinge D, et al. Medical therapy for secondary prevention and long-term outcome in patients with myocardial infarction with nonobstructive coronary artery disease. Circulation. 2017;135(16):1481-1489.
11. Hamzeh N, Steckman DA, Sauer WH, Judson MA. Pathophysiology and clinical management of cardiac sarcoidosis. Nat Rev Cardiol. 2015;12(5):278-288.
12. Yafasova A, Fosbøl EL, Schou M, et al. Long-term adverse cardiac outcomes in patients with sarcoidosis. J Am Coll Cardiol. 2020;76(7):767.777.
13. Kandolin R, Lehtonen J, Airaksinen J, et al. Cardiac sarcoidosis: epidemiology, characteristics, and outcome over 25 years in a nationwide study. Circulation. 2015;131(7):624-632.
14. Trivieri MG, Spagnolo P, Birnie D, et al. Challenges in cardiac and pulmonary sarcoidosis: JACC state-of-the-art review. J Am Coll Cardiol. 2020;76(16):1878-1901.
15. Kandolin R, Lehtonen J, Graner M, et al. Diagnosing isolated cardiac sarcoidosis. J Intern Med. 2011;270(5):461-468.
16. Hulten E, Aslam S, Osborne M, Abbasi S, Bittencourt MS, Blankstein R. Cardiac sarcoidosis — state of the art review. Cardiovasc Diagn Ther. 2016;6(1):50-63.
17. Narasimhan B, Patel N, Ho K, et al. Incidence and predictors of sudden cardiac arrest in sarcoidosis: a nationwide analysis. JACC Clin Electrophysiology. 2021;7(9):1087-1095.
18. Velangi PS, Chen KA, Kazmirczak F, et al. Right ventricular abnormalities on cardiovascular magnetic resonance imaging in patients with sarcoidosis. JACC Cardiovasc Imaging. 2020;13(6):1395-1405.
19. Lam CS, Tolep KA, Metke MP, Glockner J, Cooper LT Jr. Coronary sarcoidosis presenting as acute coronary syndrome. Clin Cardiol. 2009;32(6):E68-E71.
20. Youssef G, Beanlands RS, Birnie DH, Nery PB. Cardiac sarcoidosis: applications of imaging in diagnosis and directing treatment. Heart. 2011;97(24):2078-2087.
21. Chareonthaitawee P, Beanlands RS, Chen W, et al. Joint SNMMI-ASNC expert consensus document on the role of 18F-FDG PET/CT in cardiac sarcoid detection and therapy monitoring. J Nucl Cardiol. 2017;24(5):1741-1758.
22. Divakaran S, Stewart GC, Lakdawala NK, et al. Diagnostic accuracy of advanced imaging in cardiac sarcoidosis. Circ Cardiovasc Imaging. 2019;12(6):e008975.
23. Vita T, Okada D, Veillet-Chowdhury M, et al. Complementary value of cardiac magnetic resonance imaging and positron emission tomography/ computed tomography in the assessment of cardiac sarcoidosis. Circ Cardiovasc Imaging. 2018;11(1):e007030.
24. Sgard B, Brillet PY, Bouvry D, et al. Evaluation of FDG PET combined with cardiac MRI for the diagnosis and therapeutic monitoring of cardiac sarcoidosis. Clin Radiol. 2019;74(1):81.e9-81.e18.
25. Birnie DH, Sauer WH, Bogun F, et al. HRS expert consensus statement on the diagnosis and management of arrhythmias associated with cardiac sarcoidosis. Heart Rhythm. 2014;11(7):1305-1323.
26. Writing group; Document reading group; EACVI Reviewers: This document was reviewed by members of the EACVI Scientific Documents Committee for 2014–2016 and 2016–2018. A joint procedural position statement on imaging in cardiac sarcoidosis: from the Cardiovascular and Inflammation & Infection Committees of the European Association of Nuclear Medicine, the European Association of Cardiovascular Imaging, and the American Society of Nuclear Cardiology. Eur Heart J Cardiovasc Imaging. 2017;18(10):1073-1089.
27. Kim JS, Judson MA, Donnino R, et al. Cardiac sarcoidosis. Am Heart J. 2009;157(1):9-21.
28. Stevenson A, Bray J, Tregidgo L, et al. Prognostic value of late gadolinium enhancement detected on cardiac magnetic resonance in cardiac sarcoidosis. J Am Coll Cardiol Img. 2023;3:345-357.
29. Doughan AR, Williams BR. Cardiac sarcoidosis. Heart. 2006;92(2):282.288.
